Model
|
CMT7500
|
CMT6500
|
CMT5500
|
CMT4000
|
CMT3200
|
CMT2500
|
|
Mixing Capacity
|
7.5m³
|
6.5m³
|
5.5m³
|
4m³
|
3.2m³
|
2.5m³
|
|
Discharging Capacity per batch
|
5m³
|
4m³
|
3.5m³
|
3m³
|
2m³
|
1.5m³
|
|
Machine size(LxWxH) (mm)
|
6900*2950*3600
|
"7150*2640*4330 (Lifting arm)
8580*2640x3330 (Drop arm)
|
"6700*2640*4220(Lifting arm)
7900*2640*3120(Droparm)
|
*6700x2640*4220(Lifting arm)
7900*2640x3070 (Drop arm)"
|
*5900*2350x3900 (Lifting arm)
7100x2350*2940 (Drop arm)
|
"5300*2330*3610(Lifting arm)
6800*2330*2780(Drop arm)
|
|
Wheelbase(mm)
|
3200
|
3200
|
3200
|
3200
|
2300
|
2300
|
|
Total weight(Kg)
|
12500
|
11000
|
9500
|
0006
|
7500
|
6200
|
|
Engine
|
Yuchai6105 supercharged
country Il standard
|
Yuchai6105 supercharged
country ll standard
|
Yuchai 4108 supercharged
country ll standard
|
4105 country ll or 4102 supercharged
country Ill standard
|
Yuchai4102 supercharged
|
Yuchai4100 supercharged
|
|
Power(Kw)
Gearbox
|
92
|
92
|
91
|
85/90
|
78
|
73
|
|
Gearbox
|
315 Separated type
|
315 Separated type
|
315Separated type
|
280Separated type
|
280integral
|
265integral
|
|
Drive axle
|
front bridge 30S wet axtefrear axie 30
|
3.0Twheel side deceleration Bridge
|
2.5Twheel side deceleration Bridge
|
2.5T Wheel side deceleration Bridge
|
2.0T wheel side deceleration Bridge
|
1.8T wheel side deceleration Bridge
|
|
Tires
|
Front4/back2, 16/70-R22.5
|
16/70-R 22.5 Double tire
|
16/70 R22.5 Double tire
|
16/70-R 22.5 Double tire
|
16/70 R22.5
|
20.5-16
|
|
Bucket capacity(㎡)
|
0.7
|
0.65
|
0.65
|
0.65
|
0.5
|
0.4
|
|
Mixing capacity(㎡')
|
24.5
|
≥3.8
|
≥3.3
|
≥2.8
|
≥1.8
|
≥1.3
|
|
Reduction ratio
|
1:103
|
1:103
|
1:28
|
1:28
|
1:28
|
1:28
|
|
Rotating speed(laps/minute)
|
≥15 laps/minute
|
≥15 laps/minute
|
≥15 laps/minute
|
≥15laps/minute
|
≥15 laps/minute
|
≥15laps/minute
|
|
Reducer
|
HL6F-B2700
Made in China
|
HL6F-B2700
Made in china
|
HL6F-B2700
Made in China
|
HL6F-B2700
Made in China
|
Made in China
|
Made in China
|
|
Travel speed(km/h)
|
25
|
25
|
25
|
25
|
25
|
25
|
|
Axle number lraction type
|
4x4
|
4*4
|
4x4
|
4x4
|
4x4
|
4x4
|
